1. 8″ LCD display with touch screen
2. Temperature monitoring and servo control
3. Air temperature and body temperature control
4. Humidity monitoring and servo control
5. Mattress tilt ±12 °
6. Trend for 2, 4, 8, 12, 24 hours and up to 7 days
7. Front and rear double-walls and air curtain
8. 360°rotary drawers
9. Auxiliary Power Output*3
10. IV-Pole and shelf
11. Enhanced safety for newborns and operators with over 30 different alarm types.
12. Heating source dual protection
| Performance | |
| Air flow velocity across mattress | < 10 cm/sec |
| Temperature rise time at 22°C (72°F) ambient | < 35min (From 22°C, 50%RH, to 35°C) |
| Temperature variability | < 0.5°C |
| Temperature overshoot | < 0.5°C maximum |
| Operating noise level in hood | ≤45dBa |
| Temperature control modes | |
| Temperature control modes | Skin and Air temperature control |
| Air mode control temperature range | 20°C-37°C |
| Air mode control override temperature range | 37°C-39°C |
| Air mode control accuracy | ≤±1.0°C |
| Skin mode control temperature range | 34°C-37°C |
| Skin mode control override temperature range | 37°C-38°C |
| Servo Humidity Control | |
| Humidity control range | 30%-95% RH |
| Humidity control reservoir capacity | 1500ml |
| Humidity display and control accuracy | ±5%RH |
| Servo Oxygen Control (Optional) | |
| Oxygen control range | 21 % to 65% |
| Oxygen display accuracy of full scale | ±2% |
| Oxygen display resolution | 1% |
| Weight Scale (Optional) | |
| Weight range | 300g to 8kg |
| Weight display resolution | 1g |
| Weight accuracy | ±10g |
| Backup battery (Optional) | |
| Battery | 2600mAh, 14.8V, 38Wh |
| This battery is to keep screen, motor and alarm operation after power failure for more than 30 mins, heating and humidification functions are not supported | |
| Storage/Shipping information | |
| Temperature | -25 °C to 60 °C |
| Humidity | 0-95% RH |
