| PARAMETER | SPECIFICATION |
| DS | Range：-7.50D~+7.50D |
| Accuracy：-3.50D~+3.50D,士0.50D | |
| -7.50D~<-3.50D，士1.00D | |
| >+3.50D~+7.50D,士1.00D | |
| Pupil Size | range:4.0 mm~9.0 mm accuracy:± 0.4 mm |
| Measuring mode | Binocular mode, monocular mode |
| Inspection time | ≤3.0s |
| DC | range:0.00D~-3.00D
accuracy:士0.50D |
| Axis | range:0°~180%
accuracy: ±5° |
| Pupil Distance | range:35mm~80 mm
Accuracy：士2.0mm |
| Measuring distance | 85cm |
| Scanning characteristics | The highest scanning speed:>80000 times/second |
| Scan depth: 2.3mm | |
| Maximum scan range:12mm*9mm | |
| Light source characteristics | Centre wavelength:840nm |
| Optical power: <750μW | |
| Refractive compensation range:-20D~+25D |
