| PARAMETER | SPECIFICATION |
| Length/width | 2000mm/550mm |
| Elevation (up/down) | 680mm/930mm |
| Trendelenburg | 25° |
| Reverse Trendelenburg | 25° |
| Lateral Tilt (left/right) | 15°/15° |
| Head Rest (up/down) | 45°/90° |
| Footplate (up/down & horizontal positioning) | 15°/90° 90° |
| Back plate (up/down) | 75°/20° |
| Kidney bridge elevation | 110mm |
| Sliding | 300mm |
| Power | 220v, 50Hz, 1.0kW |
– 1 Anaesthetic Screen
– 2 Shoulder Rest
– 2 Arm Support
– 2 Waist Support
– 2 Knee Crutch
– 2 Foot Plate
– 2 Long Slider
