| PARAMETER | SPECIFICATION |
| Applicable Syringe | Various brands of sterile syringe:5ml,10ml,20ml,30ml,50ml/60ml |
| Infusion model | Rate mode, Rate-time mode, Rate-VTBI |
| Flow rate rage | 5ml syringe: 0.1-150ml/h;
10ml syringe: 0.1-300ml/h; 20ml syringe: 0.1-600ml/h; 30ml syringe: 0.1-900ml/h; 50ml(60ml) syringe: 0.1-1500ml/h |
| Volume range | 0.1ml-9999ml |
| Flow rate step | 0.1-100ml/h, increment 0.1ml/h
101-1500ml/h, increment1ml/h |
| Time preset | 1min-99:59 min |
| Accuracy | ±2％(After syringe correct calibration) |
| Alarm | Syringe not inserted, No operation, Infusion complete, Battery empty,
Occlusion, Battery low, Parameter not confirmed, AC power fail, Syringe Install Error etc. |
| KVO rate | 2.5ml/h |
| Power supply | AC power supply: 100-240V, 50/60Hz;
External DC power supply: 7.4V |
| Battery | Internal rechargeable Lithium battery,1800mAh |
| Battery working time | Around 5 hours |
| Screen | 4.3’’ LCD touch screen |
| Dimension | 220*180*80mm |
| Operation environment | Temperature +10~+30℃
Relative Humidity ≤70% Atmospheric Pressure 86Kpa~106KPa |
| Storage environment | Temperature -10~+55℃
Humidity ≤80% |
