High reliability of biosecurity
Using a fully sealed sample cup to ensure that the sample is fully sealed before、during and after testing, avoiding environmental pollution and personnel infection
Personalized sample preparation
Adopting an intelligent mixing control system, the mixing time and force are automatically adjusted according to the characteristics of the sample, ensures complete release of pathological elements from sample, and their morphology is not damaged
Dynamic fishing system
Bigger-mesh filter to keep away sample residue and smaller-mesh one to enrich pathological elements
Multi layer autofocus system
Intelligent adjustment on field of vision and automatic multi-layer focusing system captures images layer by layer and extracts parameters to avoid un-detection of pathological elements.
Unique “Cassette” design
The chemical and immunological testing kits adopt a “Cassette” design, which is plug and play, freeing up manpower. The testing items can be flexibly selected from1-10 to meet differentiated needs
Cuvettes lining-up system
Adopting high-precision disposable counting slide to reduce the risk of cross contamination, supporting time-sharing settlement of six counting slide, and improving comprehensive testing efficiency
Constant temperature incubation
Equipped with a 37℃ constant temperature incubation system and 100 incubation positions, ensuring sufficient reaction of the test kit and accurate and reliable results
Intelligent analysis and precise identification
The new Al recognition system has stronger anti-interference ability, and is continuously trained based on a massive database of thousands of users, accurately identifying various tangible components and reducing personnel review burden
Comprehensive quality controls
A comprehensive quality control supply with Fecal formed elements analysis, fecal occult blood, and transferrin to ensure testing quality
Physical Parameters
Automatic recognition of color and consistency
Rapid Test Kits
Fecal occult blood, Transferrin(support FOB Chemo-Immuno Duplex, FOB-transferrin Duplex),
Rotavirus, Adenovirus, Helicobacter pylori, Calprotectin, Lactoferrin, etc
Formed Elements
Can detect all visible components under the microscope, including RBC, WBC, Crystals, Parasite ova, Bacteria, Fat Globule, Starch granules, etc.
PARAMETER | SPECIFICATIONS |
Throughput | 40-80 T/Hour |
Recovery ratio of formed elements | ≥80% |
Precision | Comprehensive recognition and counting precision of formed elements≥95% |
Carryover ratio of formed elements | ≤1 cell/ul at concentration level of 4600-5400 cells/μl
≤2 cells/ul at concentration level of 9200-10800 cells/μl |
Sampler | Track type sampler, capable of batch processing 50 samples |
Images capture mode | Full field screening in LP, and parasite eggs can be locating in LP and tracking in HP |
Working mode | Two working mode optional, support routine samples and FEC pretreated samples running on machine |
Positive flag | Positive sample with a flag, remind user to do further verification |
STAT position | Available |
Microscope | Equipped with high and low magnification objective lens, automatic switching |
Pixel of image | ≥5 million HD pixels |
Memory | ≥200,000 results |
Network connection | Can linking the computer network of departments and hospitals, paperless transmission of test reports was realized |
Interfaces | Bidirectional with LIS/HIS |
